Intelligent PLC control system, touch screen display.
Automatic marks tracking to assure proper trademarks location.
Production count function, convenient to manage.
Monitor and alarm for jam teabag, shortage of materials, empty bags, tag paper/ thread, etc. Automatic failure shutdown.
New appearance design; meet requirements of GMP and CE certification.
The envelope paper is cold-sealed, environmental and degradable.
Options:
Heat-sealed tag device
Vibratory feeder device
Pneumatic vacuum feeder
Model | DXDD16 |
Capacity | 115±5bags/min |
Max. Dosage | 6 cm³ |
Size of tea bag (L×W) | 62.5mm×50mm |
Size of envelope (L×W) | 70mm×65mm |
Tag dimension(LxW) | 24mmx28mm (heat-sealed) |
Thread length | 210±5mm |
Power supply | AC 220V/380V(can be customized according to customer requirements) |
Total power | 1.5KW |
| Net weight | 565kg |
| Gross weight | 720kg |
| Overall dimension(LxWxH) | 1700mm×900mm×2000mm(standard) |
| Carton dimension(LxWxH) | 1236mm×1000mm×1855mm |
This system is mainly used for sorting, counting and orderly output of soft bag packaging (three-side sealing, four-side sealing, back sealing, special-shaped bags, etc.) in pharmaceuticals, food, chemicals industry, etc., and it could achieve automatic feeding of detection, boxi...
